Product Summary
The TLP421 is a GaAs IRed & Photo-Transistor.The TLP421 consists of a silicone photo-transistor optically coupled to a gallium arsenide infrared emitting diode in a four lead plastic DIP (DIP4) with having high isolation voltage.
Parametrics
TLP421 absolute maximum ratings: (1)TUV approved: DIN EN 60747-5-2 Approved no. 40010944; (2)Maximum operating insulation voltage: 1130VPK; (3)Maximum permissible over voltage: 8000VPK; (4)Creepage distance: 8.0 mm (min); (5)Clearance: 8.0 mm (min); (6)Insulation thickness: 0.4 mm (min).
Features
TLP421 features: (1)Collector−emitter voltage: 80V (min); (2)Current transfer ratio: 50% (min)Rank GB: 100% (min); (3)Isolation voltage: 5000 Vrms (min); (4)UL recognized: UL1577; (5)BSI approved: BS EN60065: 2002 Approved no. 8411 BS EN60950-1: 2002 Approved no. 8412; (6)SEMKO approved: EN60065, EN60950, EN60335 Approved no. 9910249 / 01.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLP421 |
|
PHOTOCOUPLER DC INPUT SSR 4-DIP |
Data Sheet |
Negotiable |
|
||||
 |
TLP421(GR,J) |
Toshiba |
Transistor Output Optocouplers PHOTO-TRANS W/IR 80V 5000 Vrms |
Data Sheet |
Negotiable |
|
||||
|
TLP421(GR-TP1,J) |
|
PHOTOCOUPLER TRANS-OUT 4-SMD |
Data Sheet |
Negotiable |
|
||||
|
TLP421F |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
TLP421(GR) |
|
PHOTOCOUPLER TRANS-OUT 4DIP |
Data Sheet |
Negotiable |
|
||||
|
TLP421(BL) |
|
PHOTOCOUPLER DC INPUT SSR 4-DIP |
Data Sheet |
Negotiable |
|
||||
